PFO - STATION INSTRUMENTATION

6. Global Seismograph Network - GSN

DATES OF OPERATION:	10 Jun 1993 to 29 Jun 1993.

SEISMOMETER TYPE AND ADC:
Streckeisen Model STS-1/VBB 3 component system for broadband and
very long period channels.  IDA MK7 data acquisition system.

CALIBRATION EPOCH:	1993, 161 - 1993, 180

DIGITAL FORMAT:
16 bit integer data words for all broadband (20 sps) and mid-period
(5 sps) data.  32 bit integer words for very long period (0.1 sps) data
and synthesized long period (1 sps) data.

Click on any of the following items for further information.
The Noise Study was done using 1992 data, consequently, it is only an estimation for this generation of station instrumentation.
